Google Earth Engine Tutorial: Download NDVI Images from Landsat 8

Google Earth Engine (GEE) is a powerful platform for planetary-scale environmental data analysis. One of its most common applications is extracting vegetation indices like the Normalized Difference Vegetation Index (NDVI) from satellite imagery. Landsat 8 is a widely used dataset for this purpose due to its high spatial resolution and spectral bands. Below is a step-by-step guide to downloading NDVI images from Landsat 8 using GEE.

Getting Started

To begin, you must have a Google Earth Engine account. Once registered, access the GEE Code Editor. This environment allows you to write, run, and export scripts.

Steps to Download NDVI Images from Landsat 8

1. Load the Landsat 8 Dataset

First, load the Landsat 8 Surface Reflectance dataset, which includes the necessary bands for NDVI calculation (NIR and Red).

var dataset = ee.ImageCollection('LANDSAT/LC08/C02/T1_L2');

2. Filter the Dataset

Define a date range and location to filter the data. Replace the geometry with your study area or use a predefined one.

var filtered = dataset.filterDate('2023-01-01', '2023-12-31').filterBounds(geometry);

3. Calculate NDVI

NDVI is calculated using the formula: (NIR – Red) / (NIR + Red). Use the normalizedDifference function in GEE.

var ndvi = filtered.select(['SR_B6', 'SR_B4']).map(function(image) { return image.normalizedDifference(['SR_B6', 'SR_B4']).rename('NDVI'); });

4. Export the NDVI Image

Select the most recent image and export it as a GeoTIFF using the Export.image.toDrive function.

var image = ndvi.first();

Export.image.toDrive({

image: image,

description: 'NDVI_Landsat8',

folder: 'GEE_Exports',

fileNamePrefix: 'NDVI_Landsat8',

region: geometry,

crs: 'EPSG:4326',

scale: 30,

maxPixels: 1e10

});

Example Code

// Load Landsat 8 dataset
var dataset = ee.ImageCollection('LANDSAT/LC08/C02/T1_L2');

// Define geometry (e.g., a polygon around your area of interest)
var geometry = ee.Geometry.Rectangle([left, bottom, right, top]);

// Filter by date and location
var filtered = dataset.filterDate('2023-01-01', '2023-12-31').filterBounds(geometry);

// Calculate NDVI
var ndvi = filtered.select(['SR_B6', 'SR_B4']).map(function(image) {
  return image.normalizedDifference(['SR_B6', 'SR_B4']).rename('NDVI');
});

// Export the first image in the collection
var image = ndvi.first();
Export.image.toDrive({
  image: image,
  description: 'NDVI_Landsat8',
  folder: 'GEE_Exports',
  fileNamePrefix: 'NDVI_Landsat8',
  region: geometry,
  crs: 'EPSG:4326',
  scale: 30,
  maxPixels: 1e10
});

FAQ

What is NDVI and why is it important?

NDVI (Normalized Difference Vegetation Index) measures vegetation health by comparing near-infrared and red light reflectance. It is used in agriculture, ecology, and environmental monitoring.

What parameters are required for the export?

The export requires the image to be exported, a description for the task, a folder in Google Drive, a fileNamePrefix, region or geometry, crs (coordinate reference system), scale (resolution in meters), and maxPixels to handle large areas.

Can I export NDVI in other formats besides GeoTIFF?

Yes, GEE allows exporting to formats like JPEG, PNG, or CSV, but GeoTIFF is recommended for GIS applications due to its geospatial metadata.

Why use Landsat 8 for NDVI?

Landsat 8 offers 30-meter resolution, wide temporal coverage, and free access to surface reflectance data, making it ideal for NDVI analysis at a regional scale.

What if the export takes too long?

Ensure the maxPixels parameter is set to a large enough value. Adjust the scale or region if needed to reduce processing time.
