Google Earth Engine Tutorial: Import Shapefile and Clip Raster

Import Shapefile and Clip Raster Using Google Earth Engine

Google Earth Engine (GEE) allows you to work with geospatial data by integrating remote sensing imagery with vector data, such as shapefiles. This tutorial outlines how to import a shapefile from Google Drive and use it to clip a raster dataset.

Step 1: Upload Shapefile to Google Drive

1. Convert the shapefile to a GeoJSON format or upload the ZIP file directly to your Google Drive.

2. Ensure the shapefile contains the necessary geometry (e.g., polygons, points) to define the area of interest.

Step 2: Access Shapefile in Google Earth Engine

Use the following code snippet to import the shapefile:


// Import the shapefile from Google Drive
var shapefile = ee.FeatureCollection('users/yourusername/your_shapefile_name');
// Replace 'yourusername' and 'your_shapefile_name' with your actual Drive path

Step 3: Prepare Raster Data for Clipping

Load a raster dataset, such as a Landsat image or Sentinel-2 data, and ensure it is in a compatible projection:


// Load a Landsat 8 image
var image = ee.Image('LANDSAT/LC08/C01/T1_SR');
// Filter by date and location
var filtered = image.filterDate('2020-01-01', '2020-12-31')
                   .filter(ee.Filter.eq('WRS_PATH', 137))
                   .filter(ee.Filter.eq('WRS_ROW', 34));

Step 4: Clip the Raster Using the Shapefile

Use the `clip` method to apply the shapefile’s geometry to the raster:


// Clip the image using the shapefile geometry
var clippedImage = image.clip(shapefile.geometry());

This ensures the raster is limited to the area defined by the shapefile.

Step 5: Visualize or Export the Clipped Raster

To visualize the result in the GEE Code Editor:


// Add the clipped image to the map
Map.addLayer(clippedImage, {bands: ['SR_B5', 'SR_B4', 'SR_B3'], min: 0, max: 3000}, 'Clipped Image');

To export the clipped image as a GeoTIFF:


// Export the clipped image to Google Drive
Export.image.toDrive({
  image: clippedImage,
  description: 'clipped_image',
  folder: 'GEE_Exports',
  fileNamePrefix: 'clipped_image',
  region: shapefile.geometry(),
  scale: 30,
  crs: 'EPSG:4326',
  maxPixels: 1e9
});
